    JARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reel

    Ask Lasest Price
    Brand Name : JARCH
    Model Number : JSR-L7000
    Certification : CE,FCC,ROHS
    Price : US$400-1000/SET
    Payment Terms : D/P, T/T, Western Union,PAYPAL
    Supply Ability : 1000SET/WEEK
    Delivery Time : 5-15 DAYS
    • Product Details
    • Company Profile

    JARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reel

    JARCH Bare Reel for Ethernet Cable Reels Power Cord Reels


    Product Description

    JARCH’s series L 7000 power cord reels offer many different styles of outlets. Easy to mount and structurally strong, the power cord reels have robotically welded heavy gauge steel frame that attaches to most structurally sound surfaces. For indoor, non-weather tight applications only.

    JARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reelJARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reel

    JARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reel


    We powder coat parts individually before installation for superior coverage and better protection against corrosion.You won't have to worry about your spring losing its strength or breaking from normal usage.

    Reel Specifications

    Weight41 lbs
    Series L 7000
    Cord Ending Bare Reel
    AWG 6
    Cord/Cable Length 35'
    Volts 220
    Amps 45
    Conductors 4
    Cord/Cable Included No
    Type SOOW

    Features


    ***Reinforced steel – The robotically welded steel base offers maximum strength and consistent quality.


    *** Heavy duty collector ring – A robust collector ring assures maximum conductivity current flow.


    *** Long life drive spring – Declutching arbor virtually eliminates possibility of spring damage due to reverse winding. Only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life.


    *** Quality finish and corrosion resistant – Individually powder coated components offer the maximum protection from premature corrosion.


    Packaging & Shipping
    Packaging Details:Standard Export Carton or Wooden Package
    Delivery Details:Delivery time for Sample: 5 days / Delivery time for Order depends on quantity
    Shipping:BY DHL, FedEx, UPS or TNT......

    JARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reel


    FAQ

    To increase spring tension:

    Adding wraps of hose will increase spring tension. This can be accomplished by pulling out approximately 10 feet of hose, hand feed hose back up through roller bracket assembly* until loop is large enough to slip over sheave. Add two or three wraps until desired tension is achieved. Do not exceed spring capacity.

    To reduce spring tension:

    This can be accomplished by removing wraps of hose from the reel sheave. Remove wraps of hose from the sheave, one wrap at a time, until desired tension is obtained.


    2.How do I install a new drive spring and set pre-turns?


    We have several different types of spring driven reels. Each require a slightly different set of instructions. For "How-To" instructions on replacing a drive spring please have your reel model or drive spring number available and consult customer service for instructions.


    3.Can my spring driven reel be made "constant tension"?


    While most JARCH spring retractable reels can be made "constant tension" at the factory or by simply removing the latching system there are some models that may not have this capability.

    Please contact jarch Customer Service to assure that the specific reel you have or require is capable of or available as a "constant tension" model.


    4.Reel will not latch


    This could mean it has a broken latch spring, bent latch pawl or latch plate. The broken part(s) will need to be replace.

    JARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reelJARCH Bare Ethernet Cable Compact Cable Reel , Power Cord Reels 4 Conductors spring cable reel
