Explosion proof cable reel CBDG, explosion-proof cable reel
Technical parameter:
1. Rated current: 16A * 2, 32A * 2
2. Rated voltage: AC220V / 380V
3. Explosion proof grade: Exd II BT4 / T5 / T6
4. Protection grade: IP54, IP65
Usage of the Power Electric explosion proof cable reel Drum:
1. Dangerous gas places in zone 1 and zone 2;
2. Class IA, II B, T1-T4 explosive gas or steam environment;
3. IP54,IP65
Technical features of Power Electric explosion proof cable reel Drum:
1. The shell of rotary plate and explosion-proof bolt is cast
aluminum alloy with plastic sprayed surface;
2. Small circuit breaker with leakage protection can be installed
inside;
3. There are separate and matching instructions on the plug, and
the earthing contact of the plug is longer than the main contact;
4. Connect the earthing plug first when it is inserted, and
disconnect the earthing plug after it is removed;
5. Plug and socket have interlocking device, which can be plugged
and unplugged after power failure;
6. The cable reel is flexible in rotation, with bracket and walking
wheel for easy movement
7. Standard cable length is 30m,can be extended to 100m as required
8. Reducing cabling requirements and installation costs
Product Effects
Military Grade Spring Retractable Power Electric explosion proof
cable reel Drum for electric wire rope hoist crane
Contact Us
Packaging & Shipping
| Packaging Details: | Standard Export carton Package |
| Delivery Details: | Delivery time for Sample: 5 days / Delivery time for Order depends
on quantity
Shipping:BY DHL, FedEx, UPS or TNT......
|
FAQ
1.What technical data should be provided for our customized slip ring,rotary joint union,hose reel,carbon brush model.
A:
If you want to customize the special slip ring model, you need
provide details as below:
a. Operatring speed(RPM)
b. The type of installation
c. Outline size
d. Channels(the No. of single wire besides cable)
e. Rated voltage & current for power rings and signal rings
f. The signal type and related parameters(very important)
g. Operating temperature h.IP(sealing requirements)
2. How long is your production lead time?
A: It needs 7 to 15 days for standard products, 10 to 20 days for
simple customized products,
15 to 40 days for complex customized porducts.
